LP Wizard and PCB Library Expert Comparison

PCB libraries are what we are all about - it's in our name. Libraries are not "just another thing" we do, they are our passion, strength, and focus. We want you to have the very best library solution, that is why we created it. Please compare us to the alternative...

Experience the superior option for yourself...

Download Now!!





Features

LP Wizard

Library Expert
Component package data (parts may cost extra)
11,000
1 million*
Capability (estimated components covered)**
50%
90%
IPC Compliance
IPC-7351B - 2010
IPC-7351B & C - 2017
Typical time for updates
6 months
every 1-2 weeks
Integration w/ component database
-
v2014
3D Model generation alongside footprint (standard components)***
-
Non-standard component packages
-
Pad stack Stack Designer for cutomized padstacks
-
Place pads on any grid
-
Support for ALL major CAD tools***
-
Distributed by IPC - confirm at IPC.org
-
Define Default Preferences
-
Imperial Unit friendly
-
No maintenance, buy perpetual licenses as you need them
-
Visible Silkscreen Outlines (not hidden under component body)
-
Rename pins to any alpha-numeric name
-
Pin in paste for through-hole
-
Footprint rotation
-
Mirror component to see bottom view
-
Extended Footprint Names to eliminate Duplication
-
Undo/Redo for non-standard footprint construction
-
Find duplicate parts
-
View Library Manager and Calculator simultaneously
-
3-Tier Silkscreen Outline Widths
-
3-Tier Local Fiducials
-
3-Tier Ref Des Sizes
-
Silkscreen placed outside the Body
-
Automated rounded rectangle pad shape
-
Relocate Footprint Origin on every component family
-
Set Solder Joint Rules based on package lead type
-
Via & Trace Width Calculator
-
Print
Build footprints based on component data (spec sheet)
IPC-7351B compliant (2010)
Check datasheet link
Batch Build (Multi-part)
Worldwide distributors
*The Library Expert complies with proposed requirements of upcoming IPC-7351C, as well as previous revisions. We are actively involved in the standards development to ensure our software is compliant even before the standard is published.

* Library Expert Professional users with currently released version have free access (25 parts/day) to the POD database. For others, POD parts cost $1 or $2 each, depending on complexity. Most new part requests are $5 for Pro customers and $7 otherwise. Prices subject to change without notice.

** This estimation is based on each software’s ability to create standard footprints for symmetrical components (same size pads and shapes), as well as non-standard components (different size pads and no symmetry). It is estimated that about 50% of components in the electronics industry fall into either category of standard or non-standard.

*** All Library Expert Professional outputs (CAD formats and 3D STEP) are licensed separately.
